Connecting GraphQL using Apollo Server

Introduction

Apollo Server is a library that helps you connect a GraphQL schema to an HTTP server in Node.js. We will try to explain this through an example, the link used to clone this project is mentioned below:-

git clone https://[email protected]/prwl/apollo-tutorial.git

This technology and its concepts can be best explained as below.

Challenge

Here, one of the main goals is to create a directory and install packages. This will eventually lead us to implement our first subscription in GraphQL with Apollo Server and PubSub.

Solution

For this, the first step includes building a new folder in your working directory. The current directory is changed to that new folder, and a new folder is created to hold your server code in and run. This will create the package.json file for us. After this, we install a few libraries. After the installment of these packages, the next step is to create an index.js file in the root of the server.

Create Directory

npm init -y

Install Packages

npm install apollo-server-express express graphql nodemon apollo-server

Connecting Apollo Server

Index.js first connects to the Apollo server. Every library is set to get started with the source code in the index.js file. To achieve this, you have first to import the necessary parts for getting started with Apollo Server in Express. Using Apollo Server’s applyMiddleware() method, you can opt-in any middleware, which in this case is Express.

import express from 'express';
import { ApolloServer, gql } from 'apollo-server-express';

const typeDefs = gql`
    type Query {
        hello: String
    };
const resolvers = {
    Query: {
        hello: () => 'Hello World!'
    }
}
`;
const server = new ApolloServer({ typeDefs, resolvers });
const app = express();
server.applyMiddleware({ app });

app.listen({ port: 4000 }, () =>
  console.log(`? Server ready at http://localhost:4000${server.graphqlPath}`)
);

The GraphQL schema provided to the Apollo Server is the only available data for reading and writing data via GraphQL. It can happen from any client who consumes the GraphQL API. The schema consists of type definitions, which starts with a mandatory top-level Query type for reading data, followed by fields and nested fields. Apollo Server has various scalar types in the GraphQL specification for defining strings (String), booleans (Boolean), integers (Int), and more.

const typeDefs = gql`
    type Query {
        hello: Message
    }Type Message {salutation: String}
`;
  const resolvers = {
    Query: {
        hello: () => 'Hello World!'
    }
};

In the GraphQL schema for setting up an Apollo Server, resolvers are used to return data for fields from the schema. The data source doesn’t matter, because the data can be hardcoded, can come from a database, or from another (RESTful) API endpoint.

Mutations

So far, we have only defined queries in our GraphQL schema. Apart from the Query type, there are also Mutation and Subscription types. There, you can group all your GraphQL operations for writing data instead of reading it.

const typeDefs = gql`
 type Query {
 …
 }type Mutation {createMessage(text: String!): String!}
`;

As visible from the above code snippet. In this case, the create message mutation accepts a non-nullable text input as an argument and returns the created message as a string.

Again, you have to implement the resolver as counterpart for the mutation the same as with the previous queries, which happens in the mutation part of the resolver map:

const resolvers = {
 Query: {
 hello: () => ‘Hello World!’
 },
 Mutation: {
 createMessage: (parent, args) => {
 const message = args.text;
 return message;
 },
 },
};

The mutation’s resolver has access to the text in its second argument. The parent argument isn’t used.

So far, the mutation creates a message string and returns it to the API. However, most mutations have side-effects, because they are writing data to your data source or performing another action. Most often, it will be a write operation to your database, but in this case, we are just returning the text passed to us as an argument.

That’s it for the first mutation. You can try it right now in GraphQL Playground:

mutation {
 createMessage (text: “Hello GraphQL!”)
}

The result for the query should look like this as per your defined sample data:

{
 “data”: {
 “createMessage”: “Hello GraphQL!”
 }
}

Subscriptions

So far, you used GraphQL to read and write data with queries and mutations. These are the two essential GraphQL operations to get a GraphQL server ready for CRUD operations. Next, you will learn about GraphQL Subscriptions for real-time communication between GraphQL client and server.

Apollo Server Subscription Setup

Because we are using Express as middleware, expose the subscriptions with an advanced HTTP server setup in the index.js file:

import http from ‘http’;…server.applyMiddleware({ app, path: ‘/graphql’ });const httpServer = http.createServer(app);
server.installSubscriptionHandlers(httpServer);httpServer.listen({ port: 8000 }, () => {
 console.lo;
});…

To complete the subscription setup, you’ll need to use one of the available PubSub engines for publishing and subscribing to events. Apollo Server comes with its own by default.

Let’s implement the specific subscription for the message creation. It should be possible for another GraphQL client to listen to message creations.

Create a file named subscription.js in the root directory of your project and paste the following line in that file:

import { PubSub } from ‘apollo-server’;export const CREATED = ‘CREATED’;export const EVENTS = {
 MESSAGE: CREATED,
};export default new PubSub();

The only piece missing is using the event and the PubSub instance in your resolver.

…import pubsub, { EVENTS } from ‘./subscription’;…const resolvers = {
 Query: {
 …
 },
 Mutation: {…
 },Subscription: {messageCreated: {subscribe: () => pubsub.asyncIterator(EVENTS.MESSAGE),},},};…

Also, update your schema for the newly created Subscription:

const typeDefs = gql`
 type Query {
 …
 }
 type Mutation {
 …
 }type Subscription {messageCreated: String!}
`;

The subscription as a resolver provides a counterpart for the subscription in the message schema. However, since it uses a publisher-subscriber mechanism (PubSub) for events, you have only implemented the subscribing, not the publishing. It is possible for a GraphQL client to listen for changes, but there are no changes published yet. The best place for publishing a newly created message is in the same file as the created message:

…import pubsub, { EVENTS } from ‘./subscription’;…const resolvers = {
 Query: {
 …
 },
 Mutation: {
 createMessage: (parent, args) => {
 const message = args.text;pubsub.publish(EVENTS.MESSAGE, {messageCreated: message,});
 return message;
 },
 },
 Subscription: {
 …
 },
};…

We have implemented your first subscription in GraphQL with Apollo Server and PubSub. To test it, create a new message on a tab in the apollo playground. On the other tab, we can listen to our subscription.

In the first tab, execute the subscription:

subscription {
 messageCreated
}

In the second tab execute the createMessage mutation:

mutation {
 createMessage(text: “My name is John.”)
}

Now, check the first tab(subscription) for the response like this:

{
 “data”: {
 “messageCreated”: “My name is John.”
 }
}

We have implemented GraphQL subscriptions.
